Suttner ST-007 Stainless Steel 39" Molded Handle Lance

Suttner ST-2300 Professional Pressure Washer Trigger Gun

New Professional, heavy duty, German made, Suttner ST-2300 pressure washer trigger gun. Comes with a 1/4” Female outlet and a heavy duty 3/8’’ Female inlet

SPECIFICATION:

-Maximum Pressure: 4500Psi/ 310 Bar

-Maximum Flow: 12 gal/min/ 45 Ltr/min

-Maximum Temperature: 300F/ 150C Degrees

-3/8" FNPT Inlet

-1/4" FNPT Outlet

-Safety Lock Feature

-Forged brass housing for maximum strength

-Handle constructed of impact resistant plastic

Annovi Reverberi  seal Kit 1857 for 3 pistons Pump RK, RKA, RKV series 138

Consists of:

• O'ring x3
• low pressure(suction) seal x3
• high pressure seal x3
• Seal kit for 3 pistons

ST-458.1 Orifice size 07 Pink. Rotating nozzle with ceramic insert. The increased tearing action of the rotating spray is ideal for hard surface applications, such as concrete graffiti cleaning or caked on mud on heavy equipment. Improved materials for longer life. Increases cleaning efficiency as much as 200%.

Type: ST-458
Nozzle orifice: 07 Pink
Spray angle 20°
Pressure range: 2900 - 5800 psi
Inlet: 1/4 "F.
Housing: brass
Color of protective cap: Black
Temperature: 212 °F

Pressure regulation valve VB-9 with knob, PR-5 switch and panel fitting. Brass valve body, stainless steel ball and seat. Hex-shaped non-stick check valve. Instant pressure response.

Maximum pressure: 3625 psi
Working rated pressure: 3200 psi
Maximum flow rate: 8 GPM
Rated temperature: 195°F
Input connector: 3/8 F
Outlet: 3/8 F
By pass: 3/8 F
Pressure gauge outlet: 1/4 F
Housing: forged brass
Max. Curr. Strenght 6 (2) A
Max. Voltage 250 V
Cord length: 39.4 in
International protection rating: IP 55

PR-5 Black pressure switch is a fluid operating electro-mechanical device, which, upon reaching a pre-set (start-up)pressure 40 bar/580 PSI, opens or closes an electrical control contact . Microswitch with very high resistance openings. Considerable resistance to high current values. Compact overall dimension. Three core cable.

Maximum pressure: 5076 psi
Rated working pressure: 3650 psi
Minimum pressure: 580 psi
Temperature: 167°F
Input : 1/4 F
Housing material: brass
Cord length: 37"
Max Curr./V. strength Contact: 5A-250 V
International protection rating: IP 55

PR-5 Red pressure switch is a fluid operating electro-mechanical device, which, upon reaching a pre-set (start-up)pressure 25 bar/360 psi, opens or closes an electrical control contact . Microswitch with very high resistance openings. Considerable resistance to high current values. Compact overall dimension. Three core cable.

Maximum pressure: 5076 psi
Rated working pressure: 3650 psi
Minimum pressure: 360 psi
Temperature: 167°F
Input : 1/4 F
Housing material: brass
Cord length: 37"
Max Curr./V. strength Contact: 5A-250 V
International protection rating: IP 55

ST-1500 is a most popular professional spray gun in the market.The grip housing is from impact-resistant plastic. The valve body and connectors are corrosion-resistant. The trigger is equipped with a safety lock.

Maximum pressure: 4000 psi
Maximum flow rate: 12 GPM
Temperature: 300°F
Input connector: 3/8 F
Outlet: 1/4 F
Housing: forged brass

PR-5 Blue pressure switch is a fluid operating electro-mechanical device, which, upon reaching a pre-set (start-up)pressure 15 bar/218 PSI, opens or closes an electrical control contact . Microswitch with very high resistance openings. Considerable resistance to high current values. Compact overall dimension. Three core cable.

Maximum pressure: 5076 psi
Rated working pressure: 3650 psi
Minimum pressure: 218 psi
Temperature: 167°F
Input : 1/4 F
Housing material: brass
Cord length: 37"
Max Curr./V. strength Contact: 5A-250 V
International protection rating: IP 65

Suttner ST-54 Stainless Steel 38" Molded Handle,Twin lance. 15 degrees bended input 1/4"MPT, 2 outlets 1/4"F with nozzle ST-10 protector and low pressure nozzle. High pressure nozzle is NOT included. Made in Germany. For use when high and low pressures are needed.

For example, spraying cleaning agents with low pressure through an injector valve and then cleaning with high pressure. Lance 15° bended with molded handle, valve ST-54 aside, nozzle protector ST-10 with low pressure nozzle & 1/4" F thread

Pressure regulation valve VB 9 with knob and panel fitting. Brass valve body, stainless steel ball and seat. Hex-shaped non-stick check valve.

Maximum pressure: 3625 psi
Working rated pressure: 3200 psi
Maximum flow rate: 8 GPM
Rated temperature: 195°F
Input connector: 3/8 F
Outlet: 3/8 F
By pass: 3/8 F
Pressure gauge outlet: 1/4 F
Housing: forged brass

PA VT-6. Thermal relief valve. Valve bypasses water, reaching the off-temperature. High temperature pump protection valve with copper sonde.

Maximum pressure: 145 psi
Opening Temperature: 145°F
Input : 3/8 M
Output: hose tail 1/4
Housing material: brass

ST-10 is 2 component nozzle protector. Made out of hard plastic and soft edge protecting sensitive surfaces against damage . Stainless steel body. The nozzle protector suitable for cold and hot water applications in the car wash, agriculture, food industry. ST-10 is unimpeachable, protects your nozzles and preserves the surfaces to be cleaned at the same time. Suitable for nozzles 1/8" M NPT.

Maximum pressure: 7250 psi
Rated temperature: 300°F
Input: 1/4 F NPT
Outlet: 1/8 F NPT
Housing: Stainless Steel
Protection material: Hard plastic/Soft edge

ST-60.1 Downstream Suttner foam injector with chemical metering valve, suction hose and ST-31 chemical strainer, quick couplings nickel/zinc plated brass ST-45-250 KEW, Nilfisk-Alto. Mixing of chemicals approx. 0-11.5%.Metering valve hose tail 1/4. Suction hose 39" long.Injector with dosage ST-61. Orifice size 1.6 mm.

Maximum pressure: 3625 psi
Minimum flow rate: 1.6 GPM
Maximum flow rate: 15.2 GPM
Temperature: 140°F
Housing: forged brass
Nozzle: Stainless steel
Input coupling: ST-45-250 KW
Output connector: ST-45-250 KW
Suction hose lenght: 39"

PMEG nozzles is high impact washJet flat spray nozzles are ideal for pressure washing, cleaning and car wash applications. Advantages of Power-MEG nozzles is: 3 time faster, saves up to 60% water, 3 times higher impact. Hardened stainless steel construction provides long wear life and flow control accuracy. Recommended for surface cleaner use. The WashJet product line, however, was designed specifically to operate in high-pressure applications and will provide improved cleaning effectiveness and a better distribution of impact across the entire spray pattern.

Type: PMEG
Nozzle orifice: 06
Spray angle 15°
Pressure range: 300 to 4000 psi (20 to 275 bar)
Inlet: 1/8 "M.
Housing: Hardened stainless steel

Suttner repair kit for ST-2300/2600 Pressure washer trigger gun. With instructions inside. Made in Germany.

-Instructions inside

-Fits ST2300/2600/2305/2605

-Kit for repairing Suttner Pressure washer guns

-Manufacturer: Suttner

Suttner Pressure Switch ST-7.1 (RED-25 bar/362 psi) for Pressure Washer. Made in GERMANY

SPECIFICATION:

-Operating (start up) pressure: 25 bar/ 362 psi

-Rated pressure: 300bar/ 4350psi

-Rated temperature: 90C/ 194F

-Max Voltage: 250V

-Max Current strength: 10.1A

-Electrical Insulation rating: 65 IP

-Material: Brass

-Color: Black

-Inlet: 1/4” M

-Cable length: 950mm/ 37 Inches
