ST-49.1 rotating sewer cleaning nozzle. Nozzle size 055. Female 1/4. Material Ss and brass . Made in Germany
Suttner rotating nozzle for sewer cleaning ST-49.1. Without centric hole, very good cleaning effect due to rotating nozzle jets.
SPECIFICATION:
-Maximum pressure: 4000psi
-Input: 1/4” F
-Housing: Stainless Steel and Brass
-Ports: 3 rear jets
-Nozzle size: 055
Data sheet
Quick Screw Coupling (nipple) M22X1,5:1/4"M
Maximum pressure: 5800 psi
Temperature: 300°F
Input: M22 M
Outlet: 1/4 M
Housing: brass
Height 29 mm
St-33 Water intake T-strainer filter complete with filter fine core washable (stainless steel and plastic).
Maximum pressure: 87 psi
Maximum flow rate: 13.2 GPM
Temperature: 140°F
Input: 3/4 F
Outlet: 3/4 M
Housing: plastic
Screen material: stainless steel+plastic
Screen Microns: 50
PMEG nozzles is high impact washJet flat spray nozzles are ideal for pressure washing, cleaning and car wash applications. Advantages of Power-MEG nozzles is :3 time faster, saves up to 60% water, 3 times higher impact. Hardened stainless steel construction provides long wear life and flow control accuracy. Recommended for surface cleaner use. The WashJet product line, however, was designed specifically to operate in high-pressure applications and will provide improved cleaning effectiveness and a better distribution of impact across the entire spray pattern.
Type: PMEG
Nozzle orifice: 04
Spray angle 15°
Pressure range: 300 to 4000 psi (20 to 275 bar)
Inlet: 1/4 "M.
Housing: Hardened stainless steel
ST-40 Quick screw couplings M22fX1,5:3/8F. Suitable for Karcher and more.
Maximum pressure: 5800 psi
Temperature: 300°F
Input: M22 F
Outlet: 3/8" F
Housing: brass/plastic
Height 45 mm
Our easyfoamer ST-73.1 realizes an ideal mixing of air and cleaning agent, thus succeeding an ideal foam result. Nozzle size 1.25.
completely stainless steel and
non-corrosive injector unit
the highest grade of chemical resistance
5 defined dosing positions
0.265 gal bottle
vertical or horizontal spray pattern
patent pending
Pressure max. 4350 psi
Temperature 176 F
P.A. Unloader pressure Regulation valve VB 85/280 Blue Spring, knob is not included.
SPECIFICATION:
-Maximum pressure: 4500 psi
-Working rated pressure: 4050 psi
-Inlet 1/2" F
-Outlet 1/2" F
-Bypass 1/2" F
-Maximum flow rate: 21 GPM
-Rated temperature: 195°F
-Housing: forged brass
-Material: brass
-Manufacturer: PA
ST-49 non-rotating sewer cleaning Grease ball nozzle. Female 1/4 8x06R. Ss hardened. Made in Germany
The Grease ball features 8 rear jets (0.6 mm) for extreme thrust and highest wall coverage of the pipe. Designed for the ability to clean grease off the sidewall of pipes but has proven to be great on root chokes too. Completely spherical shape. Nozzle drilling as stepped bore for best protection against mechanical impact. Good for 2”-6” inch lines.
Suttner ST-54 Stainless Steel 38" Molded Handle,Twin lance. 15 degrees bended input 1/4"MPT, 2 outlets 1/4"F with nozzle ST-10 protector and low pressure nozzle. High pressure nozzle is NOT included. Made in Germany. For use when high and low pressures are needed.
For example, spraying cleaning agents with low pressure through an injector valve and then cleaning with high pressure. Lance 15° bended with molded handle, valve ST-54 aside, nozzle protector ST-10 with low pressure nozzle & 1/4" F thread
ST-60.1 Downstream Suttner foam injector with chemical metering valve, suction hose and ST-31 chemical strainer, quick couplings nickel/zinc plated brass ST-45-250 KEW, Nilfisk-Alto. Mixing of chemicals approx. 0-11.5%.Metering valve hose tail 1/4. Suction hose 39" long.Injector with dosage ST-61. Orifice size 1.6 mm.
Maximum pressure: 3625 psi
Minimum flow rate: 1.6 GPM
Maximum flow rate: 15.2 GPM
Temperature: 140°F
Housing: forged brass
Nozzle: Stainless steel
Input coupling: ST-45-250 KW
Output connector: ST-45-250 KW
Suction hose lenght: 39"
Pressure regulation valve VB-9 with knob, PR-5 switch and panel fitting. Brass valve body, stainless steel ball and seat. Hex-shaped non-stick check valve. Instant pressure response.
Maximum pressure: 3625 psi
Working rated pressure: 3200 psi
Maximum flow rate: 8 GPM
Rated temperature: 195°F
Input connector: 3/8 F
Outlet: 3/8 F
By pass: 3/8 F
Pressure gauge outlet: 1/4 F
Housing: forged brass
Max. Curr. Strenght 6 (2) A
Max. Voltage 250 V
Cord length: 39.4 in
International protection rating: IP 55
Valve set for Annovi Reverberi RK Series 138, 228. A&R part number (1389051).Valve kit number 2864.
Consists of:
The ST-2300 is a professional high pressure cleaning gun with coupling KW. Famous quick coupling system for accessories, quicker to connect and disconnect lance, reducing downtime.(KEW, Nilfisk- Alto) The grip housing is from impact-resistant plastic. The valve body and connectors are corrosion-resistant. The trigger is equipped with a safety lock.
Maximum pressure: 4500 psi
Minimum pressure: 145 psi
Recommended pressure: 4000 psi
Maximum flow rate: 12 GPM
Temperature: 300°F
Input connector: 3/8 F
Outlet: Coupling KW
Housing: forged brass
ST-456 Orifice size 05 Black. Rotating nozzle with ceramic insert. The increased tearing action of the rotating spray is ideal for hard surface applications, such as concrete graffiti cleaning or caked on mud on heavy equipment. Improved materials for longer life. Increases cleaning efficiency as much as 200%.
Type: ST-456
Nozzle orifice: 05 black
Spray angle 20°
Pressure range: 2900 - 5076 psi
Inlet: 1/4 "F.
Housing: brass
Color of protective cap: Black
Temperature: 212 °F
Spray angle: 20°
Nozzle protector. It's made out of soft Rubber which protects sensitive surfaces against damage. It also has a zinc-plated body. The nozzle protector is suitable for cold and hot water applications in the car wash, agriculture. Suitable for nozzles 1/4" M NPT.
Maximum pressure: 5800 psi
Rated temperature: 300°F
Input: 1/4 F NPT
Outlet: 1/4 F NPT
Housing: Zinc-plated steel
Protection material: Rubber
ST-458.1 Orifice size 05 Black. Rotating nozzle with ceramic insert. The increased tearing action of the rotating spray is ideal for hard surface applications, such as concrete graffiti cleaning or caked on mud on heavy equipment. Improved materials for longer life. Increases cleaning efficiency as much as 200%.
Type: ST-458
Nozzle orifice: 05 Black
Spray angle 20°
Pressure range: 2900 - 5800 psi
Inlet: 1/4 "F.
Housing: brass
Color of protective cap: Black
Temperature: 212 °F
ST-49.1 rotating sewer cleaning nozzle. Nozzle size 05. Female 3/8. Material Ss and brass . Made in Germany
Suttner rotating nozzle for sewer cleaning ST-49.1. Ideal for 4”-8” lines. Without centric hole, very good cleaning effect due to rotating nozzle jets.
