Flow Switch ST-7 1.5 L/Min - 0.4 GPM

PA VT-6. Thermal relief valve. Valve bypasses water, reaching the off-temperature. High temperature pump protection valve with copper sonde.

Maximum pressure: 145 psi
Opening Temperature: 145°F
Input : 3/8 M
Output: hose tail 1/4
Housing material: brass

Suttner ST-6 Flow Switch, All position (Horizontal or Vertical) Spring assisted brass magnet. Made in Germany

FEATURES:

-Horizontal or vertical mount

-Easy brass reed switch replacement.

SPECIFICATION:

-Max. Pressure: 5,070 PSI/350 bar.

-Min. Pressure: 75 PSI

-Max. Flow Rate: 8 GPM/ 30 ltr.

-Min. Flow Rate: 1 GPM

-Max Voltage: 250 V

-Max Current: 1 Amps

-Max: Fluid Temperature: 180° F/ 80 ° C

-Cable Length: 47.0 in/ 1200 mm.

-Inlet & Outlet: 3/8 MNPT

-Housing: Forged Brass

Connection for spray guns with coupling KW. Famous quick coupling system for accessories, quicker to connect and disconnect lance, reducing downtime.(KEW, Nilfisk-Alto) For lances moulded handles. Installation recommendation: Seal with liquid thread sealant only.

Material: stainless steel
Temperature: 300°F
Input connector: Coupling KW
Outlet: 1/4" F

St-33 Water intake T-strainer filter complete with filter fine core washable (stainless steel and plastic).

Maximum pressure: 87 psi
Maximum flow rate: 13.2 GPM
Temperature: 140°F
Input: 3/4 F
Outlet: 3/4 M
Housing: plastic
Screen material: stainless steel+plastic
Screen Microns: 50

ST-5 Flow switch (grey universal). Mounts in horizontal or vertical position (any position). Magnet with hole.

Maximum pressure: 5076 psi
Minimum pressure: 75 psi
Minimum flow rate: 1 GPM
Maximum flow rate: 7.8 GPM
Temperature: 180°F
Input : 3/8 F
Outlet: 3/8 F
Housing: brass
Brass reed switch cord length: 47"
Contact: 1A-250 V

Suttner Pressure Switch ST-7.1 (RED-25 bar/362 psi) for Pressure Washer. Made in GERMANY

SPECIFICATION:

-Operating (start up) pressure: 25 bar/ 362 psi

-Rated pressure: 300bar/ 4350psi

-Rated temperature: 90C/ 194F

-Max Voltage: 250V

-Max Current strength: 10.1A

-Electrical Insulation rating: 65 IP

-Material: Brass

-Color: Black

-Inlet: 1/4” M

-Cable length: 950mm/ 37 Inches

1702747 A&R Seal Kit 2747 for 3 pistons, Pump XM, Series X-Pro, 9, 178

Consists of:

-O-ring X3

-Low pressure (suction) seal X3

-High pressure seal X3

-Seal kit for 3 pistons

ST-456 Orifice size 04 Brown. Rotating nozzle with ceramic insert. The increased tearing action of the rotating spray is ideal for hard surface applications, such as concrete graffiti cleaning or caked on mud on heavy equipment. Improved materials for longer life. Increases cleaning efficiency as much as 200%.

Type: ST-456
Nozzle orifice: 04 brown
Spray angle 20°
Pressure range: 2900 - 5076 psi
Inlet: 1/4 "F.
Housing: brass
Color of protective cap: Black
Temperature: 212 °F
Spray angle: 20°

ST-357.1 Orifice size 05 Black. Rotating nozzle with ceramic insert. The increased tearing action of the rotating spray is ideal for hard surface applications, such as concrete graffiti cleaning or caked on mud on heavy equipment. Improved materials for longer life. Increases cleaning efficiency as much as 200%.

Type: ST-357
Nozzle orifice: 05 Black
Spray angle 20°
Pressure range: 1450 - 3625 psi
Inlet: 1/4 "F.
Housing: brass
Color of protective cap: Black
Temperature: 212 °F

ST-456 Orifice size 05 Black. Rotating nozzle with ceramic insert. The increased tearing action of the rotating spray is ideal for hard surface applications, such as concrete graffiti cleaning or caked on mud on heavy equipment. Improved materials for longer life. Increases cleaning efficiency as much as 200%.

Type: ST-456
Nozzle orifice: 05 black
Spray angle 20°
Pressure range: 2900 - 5076 psi
Inlet: 1/4 "F.
Housing: brass
Color of protective cap: Black
Temperature: 212 °F
Spray angle: 20°

ST-1500 is a most popular professional spray gun in the market.The grip housing is from impact-resistant plastic. The valve body and connectors are corrosion-resistant. The trigger is equipped with a safety lock.

Maximum pressure: 4000 psi
Maximum flow rate: 12 GPM
Temperature: 300°F
Input connector: 3/8 F
Outlet: 1/4 F
Housing: forged brass

PMEG nozzles is high impact washJet flat spray nozzles are ideal for pressure washing, cleaning and car wash applications. Advantages of Power-MEG nozzles is: 3 time faster, saves up to 60% water, 3 times higher impact. Hardened stainless steel construction provides long wear life and flow control accuracy. Recommended for surface cleaner use. The WashJet product line, however, was designed specifically to operate in high-pressure applications and will provide improved cleaning effectiveness and a better distribution of impact across the entire spray pattern.

Type: PMEG
Nozzle orifice: 055
Spray angle 15°
Pressure range: 300 to 4000 psi (20 to 275 bar)
Inlet: 1/4 "M.
Housing: Hardened stainless steel

ST-49.1 rotating sewer cleaning nozzle. Nozzle size 055. Female 1/4. Material Ss and brass . Made in Germany

Suttner rotating nozzle for sewer cleaning ST-49.1. Without centric hole, very good cleaning effect due to rotating nozzle jets.

ST-49.1 rotating sewer cleaning nozzle. Nozzle size 05. Female 1/8. Material Ss and brass . Made in Germany

Suttner rotating nozzle for sewer cleaning ST-49.1. Ideal for 1”-3” lines. Without centric hole, very good cleaning effect due to rotating nozzle jets.

PMEG nozzles is high impact washJet flat spray nozzles are ideal for pressure washing, cleaning and car wash applications. Advantages of Power-MEG nozzles is: 3 time faster, saves up to 60% water, 3 times higher impact. Hardened stainless steel construction provides long wear life and flow control accuracy. Recommended for surface cleaner use. The WashJet product line, however, was designed specifically to operate in high-pressure applications and will provide improved cleaning effectiveness and a better distribution of impact across the entire spray pattern.

Type: PMEG
Nozzle orifice: 045
Spray angle 15°
Pressure range: 300 to 4000 psi (20 to 275 bar)
Inlet: 1/4 "M.
Housing: Hardened stainless steel

PMEG nozzles is high impact washJet flat spray nozzles are ideal for pressure washing, cleaning and car wash applications. Advantages of Power-MEG nozzles is: 3 time faster, saves up to 60% water, 3 times higher impact. Hardened stainless steel construction provides long wear life and flow control accuracy. Recommended for surface cleaner use. The WashJet product line, however, was designed specifically to operate in high-pressure applications and will provide improved cleaning effectiveness and a better distribution of impact across the entire spray pattern.

Type: PMEG
Nozzle orifice: 055
Spray angle 15°
Pressure range: 300 to 4000 psi (20 to 275 bar)
Inlet: 1/8 "M.
Housing: Hardened stainless steel
